Purple Cobble Ledge Climbing Hold

A ledge/jug hold for vertical to very angled walls

11/15/23 This is 1 of 12 climbing holds of my first rock climbing hold pack. I just listed the pack on cgtrader and Cults3D for a very reasonable price! I have created all of these holds myself and I think they are very unique and offer great versatility for your home climbing wall!

Here is the link to the pack:

https://www.cgtrader.com/3d-print-models/hobby-diy/other/star-pack-climbing-holds https://cults3d.com/en/3d-model/tool/star-pack-climbing-holds

Mounting information:

3/8-16 bolt hole with 3/8 washer (3/4 OD washer)

No. 10 screw for the screw hole

DO NOT OVERTIGHTEN

Print with eSlicer's fuzzy skin experimental setting for texture, fuzzy skin settings used:

Fuzzy skin thickness: 0.3 (mm)

Fuzzy skin density = 6.0 (1/mm)

Fuzzy skin Point Distance = 0.1667 (mm)

Infill should be at least 30%, with at least 6 walls

I only weigh about 145 pounds and I've never had a hold break on me but be responsible and don't skimp out on material and print with more infill/walls for a stronger hold

Enjoy and let me know if there are any particular holds you want designed for your home walls! Also leave a comment if you need a version with different mounting holes, I will quickly add another STL file with custom bolt holes and screw holes if you need it.

Print Settings

Printer Brand:

Creality

Printer:

Ender-3 v2

Rafts:

No

Supports:

Yes

Resolution:

.3

Infill:

≥30
